QNAP QVP-85B, 8-bay ultra-performance NVR server,Intel® Core™ i5 6-core/12-thread Processor,32 GB SODIMM DDR4 (2 x 16 GB), 2 year RTB

Product May Vary From Image
Our Price:
$5,938.70
Quantity:
Part No:
562744
Brand:
QNAP
Manuf No:
QVP-85B

QVP85B
Usually Ships:
Order In   More info
Ship Weight:
7.34 KG  Details
Product Description

The QVP-85B QVR Pro is a tower-based network surveillance server with an Intel Core multi-core processor that supports eight free IP camera channels and up to sixty-four IP camera channels. Offering an economic and high-performance software and hardware integrated video surveillance solution, the QVP-85B fulfills requirements for secure, reliable, and centrally-managed video surveillance storage for small businesses and offices.

intel-core-i5

  • Support ONVIF cameras

    Supports thousands of cameras from over 200+ brands and ONVIF standards.

  • Surveillance management

    Monitor and manage cameras from Windows, Mac and mobile devices.

QVP-85B vs. other NAS-based surveillance systems. Whats the difference?

In a conventional NAS-based surveillance system, surveillance is just one of many applications available to users. As all these applications need to share NAS system resources and storage space, surveillance performance could be impacted. The QVP-85B QVR Pro Appliance overcomes this by providing dedicated storage space and reserving full system resources for surveillance, delivering the utmost performance to fulfill professional surveillance system requirements. The QVP-85B also comes with built-in camera channel licenses and essential applications to enable local installation without requiring an internet connection. Simply install the hard drives and power up the QVP-85B to start the installation process.

High-capacity video surveillance storage solution

QVP-85B is a professional network surveillance server, compatible with 8,000+ IP cameras of 200+ brands and thousands of ONVIF network cameras.

Comprehensive camera support and management

The QVP-85B supports thousands of camera models from over 200+ brands with a variety of image formats (including cameras that use ONVIF and RTSP/ HTTP streaming). Even USB webcams are supported, allowing home and budget-conscious users to quickly build surveillance solutions tailored to their environment while providing convenient camera management.

Motion detection using budget-friendly USB webcams

Standard surveillance systems normally only support event recording and notification functions for expensive cameras with integrated motion detection. The QVP-85B provides motion detection even for entry-level cameras and USB webcams. As long as your camera can stream its footage to the QVR Pro appliance (e.g. through RTSP protocol) it supports motion detection, allowing you to build a budget-friendly, motion-detecting surveillance system.

QVR Pro Client

The QVR Pro Client software can be installed on Windows and Mac devices, allowing you to monitor from different platforms and flexibly switch from live view or playback mode to take full control over monitored areas.

  • Live view and playback

    Monitor the live view of multiple channels and play recordings on a single interface. You can also view recordings at a specific time by clicking the timeline or by defining a time range.

  • Region of Interest

    The Region of Interest (ROI) feature allows for viewing multiple regional images from the same camera in live view and playback mode. You can define and enlarge multiple areas to watch the area more closely.

  • Qdewarp Technology

    The innovative Qdewarp enables users to view standard fisheye camera recordings in proportional ratios and sizes without affecting original recordings. The distorted parts on the edges can be turned into a clear panoramic view.

  • Multiple Notification Methods

    The event notification provides multiple ways of being informed of emerging events, including flashing red borders of channels, alert buzzers, and the motion icon on the e-map.

Easy remote monitoring with the QVR Pro Client mobile app

The QVR Pro Client mobile app allows you to remotely monitor multiple channels simultaneously. If your network connection is slow or metered/capped, you can choose the low-bandwidth mode to view a bandwidth-optimized stream without affecting the quality of recordings. In addition, you can remotely set the cameras preset point or control the PTZ cameras within the app.

Expand your surveillance applications Control, failover, and facial recognition

  • QVR Center
    QVR Pro control center

    Centrally manage multiple QVR Pro servers installed in different areas. You can also centrally monitor live feeds, play back recordings and receive event notifications from multiple QVR Pro servers, helping you reduce response times to events.

    Learn More:QVR Center

  • QVR Guard
    High-availability failover management

    Protect QVR Pro from system failure to ensure uninterruptible surveillance recordings. If your QVR Pro fails or crashes, QVR Guard automatically takes over recording tasks, providing dependable redundancy for your surveillance system.

    Learn More:QVR Guard

  • QVR Face
    Smart facial recognition and analytics

    Obtain real-time video analytics from connected cameras and use them to set profiles, groups, and event notifications for instant facial recognition. This is ideal for smart retail, door access management, and VIP welcoming systems.

    Learn More:QVR Face

Smoother surveillance streaming with 2.5GbE connectivity

Connect the two built-in 2.5GbE ports to a QNAP 2.5GbE switch to benefit from a smoother surveillance streaming experience.

Flexible Storage Expansion

Connect TL SATA JBODs:TL-D400S,TL-R400S,TL-D800S,TL-D1600Sto expand the storage capacity of the QVP-85B to accommodate data and business growth.

Extend hardware warranty up to 5 years

The QVP-85B is backed by a 3-year warranty at no additional cost. You can also purchase a warranty extension that extends your warranty coverage up to 5 years.

Learn More:QNAP warranty services


QVP-85B

OSQVR Pro OS (QVP)
CPUIntel Core i5 6-core/12-thread Processor
CPU Architecture64-bit x86
Graphic ProcessorsIntel UHD Graphics 730
Hardware-accelerated Transcoding
System Memory32 GB SODIMM DDR4 (2 x 16 GB)
Maximum Memory64 GB ( 2 x 32 GB)
Memory Slot2 x SO-DIMM DDR4
Flash Memory5GB (Dual boot OS protection)
Max Live Cameras (Local Display)56ch @ All 720p,H.264, 30FPS
34ch @ All 1080p,H.264, 30FPS
Max Playback Cameras (Local Display)16
Max Concurrent Connection (Client)16 (4 live cameras / per remote client)
*The number of client concurrent connection varies by live cameras
Embedded Channel8
Max Channel64
H264 / 1920x1080 / 30FPS
Max Throughput1686 Mbps
Drive Bay8 x 3.5-inch SATA 6Gb/s, 3Gb/s
The system is shipped without HDD.
For the HDD compatibility list, please visithttps://www.qnap.com/compatibility/
Drive Compatibility3.5-inch bays:
3.5-inch SATA hard disk drives
2.5-inch SATA hard disk drives
2.5-inch SATA solid state drives
Hot-swappable
M.2 SSD Slot2 x M.2 2280 PCIe Gen4 x4 slots
M.2 SSD Slot_note (nvme or sata)These M.2 slots do not support features related to QVP software
2.5 Gigabit Ethernet Port2
PCIe Slot2
Slot 1: PCIe Gen 4 x16
Slot 2: PCIe Gen 4 x4
USB 3.2 Gen 2 (10Gbps) Port1 x Type-C USB 3.2 Gen 2 10Gbps
2 x Type-A USB 3.2 Gen 2 10Gbps
HDMI Output1, HDMI 1.4b (up to 4096 x 2160 @ 30Hz)
Form FactorTower
LED IndicatorsHDD 1-8, Status, LAN, USB port, M.2 port
LCD Display/ ButtonYes
ButtonsPower, Reset, USB Copy
Dimensions (HxWxD)188.2 329.3 280.8 mm
Weight (Net)7.3 kg
Operating temperature0 - 40 C (32F - 104F)
Relative Humidity5-95% RH non-condensing, wet bulb: 27C (80.6F)
Power Supply Unit250W, 100-240V
Power Consumption: HDD Sleep Mode43.131 W
Power Consumption: Operating Mode, Typical85.701 W
With WD10EFRX drives fully populated
FanSystem fan: 2 x 120mm, 12VDC
CPU fan: 1 x 60mm, 12VDC
Sound Level24.2 db(A)
System WarningVoice prompts or Buzzer
Tray LockerYes
File System: Internal Hard DriveEXT4
RAID Recovery
Online RAID Capacity Expansion
Online RAID Level Migration
RAID 10+ hot spare
RAID 10
RAID 6+ hot spare
RAID 6
RAID 5+ Spare
RAID 5
RAID 1
JBOD
Single Disk
Global Hot Spare
Wake on LAN (WOL)
Schedule Power On/Off (15 settings)
Telnet & SSH logins (Admin only)
Syslog Server & Client
LanguageEnglish, German, French, Italian, Spanish, Polish, Swedish, Danish, Norwegian, Finnish, Russian, Japanese, Korean, Dutch, Czech, Traditional Chinese, Simplified Chinese, Turkish, Hungarian, Romanian, Thai, Portuguese/Brazil, Greek
Note: Use only QNAP memory modules to maintain system performance and stability. For NAS devices with more than one memory slot, use QNAP modules with identical specifications and refer to the hardware user manual to install compatible QNAP memory modules.
Warning: Using unsupported modules may degrade performance, cause errors, or prevent the operating system from starting.
QNAP reserves the right to replace partial parts or accessories if the original is no longer available from its manufacturer/supplier. Any replacement would be fully tested and verified to meet strict compatibility and stability guidelines and will deliver identical performance to the original.
The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI trade dress and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.
Product images are for illustrative purposes only and may differ from the actual product. Due to differences in monitors, colors of products may also appear different to those shown on the site.
Designs and specifications are subject to change without notice.






Product Warranty


1 Year Return to Base
