Networkable DVR for remote viewing over the web. 'Set & Forget' with your optional hard drive.
State of the art features including motion detection, alert & on-screen programming.
Your home & business safety net. One of the world's most popular 4 channel digital video recorders! Just add cameras!
MPEG4/MJPEG DVR Technology Compression format providing crystal clear images with real time performance
Multiplex Allow live display, record, playback, backup and network operation at the same time
Backup Function Support network remote recording & backup
Remote Surveillance Remote surveillance with the licensed software AP and IE browser
Web surveillance with 5 users simultaneously
Intelligent Motion Trigger Recording With advanced settings for motion detection, scheduled motion detection recording
(4 different adjustable factors for the motion detection sensitivity) and convenient search function, customized security environment is achieved
Alarm triggered recording will send alerts with images to the designated e-mails and FTP address
Support pre-alarm recording (8Mb)
Covert Recording A mask replaces the live image with a blank screen, and the monitor shows nothing but recording is still on AV Support
Support 1 audio-in, 1 audio-out to record sounds
General Support multi-language OSD
System auto recovery after power reconnected
Support daylight-saving function
Support manual / timer / motion / alarm / remote recording functions
Watermark function ensures authentication of the recorded images
Support TCP/IP, PPPoE, DHCP and DDNS network connection

|
| |
| |
| Product Info |
Features
- Monitor & record up to 4 cameras simultaneously with this affordable, networkable DVR (HDD Optional)
- Option of MPEG4 or MJPEG allows for the enhanced frame rate of MJPEG or the higher compression and faster streaming of MPEG4
- Variable compression recording allows for high quality video play-back or increased disk storage capacity
- Easy remote viewing 24/7 over the web or local network
- Simple to connect to your PC, security monitor or TV via AV cable & ideal for use with 4 Swann security cameras
- Protect your business, oversee customers, staff, store, reduce theft, monitor your parking lot, showroom & more!
|
|
| Specifications |
|
|
Video |
|
Video Format:
|
NTSC or PAL |
|
Video Inputs
|
4 Composite BNC Inputs |
|
Video Outputs:
|
1 Composite BNC Output |
|
Display Resolution
|
NTSC: 720 x 480
PAL: 720 x 576 |
|
Display Frame Rate
|
NTSC: 120fps
PAL: 100fps |
|
|
Audio
|
|
Audio Input
|
N/A |
|
Audio Output
|
N/A |
|
|
Recording |
|
Compression Format
|
MPEG4 / MJPEG
|
|
Recording Resolution
|
NTSC: 720 x 480
PAL: 720 x 576 |
|
Recording Frame Rate:
|
NTSC: 120 fps CIF
PAL: 100 fps CIF
|
|
Recording Modes:
|
Manual / Timer / Motion / Remote |
|
Multiplex Operation
|
Triplex |
|
HDD Interface / Memory Type:
|
SATA |
|
Hard Drive Support
|
(OPTIONAL)
Up to 400GB |
|
|
Network |
|
LAN Connection:
|
Yes |
|
Network Interface:
|
RJ45 |
|
Network Protocol:
|
TCP/IP, DHCP, DDNS, PPPOE |
|
Remote Operation:
|
Yes |
|
|
General |
|
Operating Power:
|
DC 19V |
|
Dimensions
|
13.5" x 2.3" x 8.8"
343mm x 59mm x 223mm |
|
Weight
|
3.9lbs / 1.8kg |
|
Back-up Method
|
Network / Remote Backup |
|
Mouse Support
|
No |
|
Remote Control
|
No |
|
Remote Control Battery Type
|
N/A |
|
|
| |
| Labelled Diagram |
|
|
| |
| What's in Box? |
|
Contents
- DVR4-Pro-Net DVR
- 4 x Window Security Stickers
- User Manual CD
- Quick Start Guide & Network
Viewing Software
- Power Supply with Power Cord
- Bag of HDD Screws
- I/O Port Adapter Plug Parts
- Hard Drive Data Cable
|
| |
*Note: Product contents may change without notice.
|
|
| |
| |
| |
|
|
|
