Camera
|
|
Image Sensor
|
1/3" SONY progressive scan CCD
|
|
Picture Elements
|
1280(H) x 960 (V), 1.3M CCD
|
|
Resolution
|
700 TVL
|
|
Minimum Illumination
|
0.1 lux @ F1.2
|
|
Shutter Speed
|
1.5 ~ 1/10000 sec.
|
|
White Balance
|
Manual / ATW (1500 ~ 15000K)
|
|
Lens
|
|
Max Aperture
|
Wide F1.4, Tele F2.9 |
| Lens Focal |
f = 3.3~12 mm
|
|
Angle of View
|
Wide end
|
Diagonal 125.7 / Horizontal 89.8 |
|
Tele end
|
Diagonal 29.9 / Horizontal 23.9 |
|
Operation
|
|
Video Codec
|
MPEG4 / MJPEG
|
|
Video Streaming
|
Simultaneous MPEG4 and MJPEG video stream (dual stream)
Selectable single stream (MPEG4 or MJPEG)
|
|
Resolution
|
MPEG4 ASP: VGA, QVGA, CIF, QCIF
MJPEG: 1280x960(4 VGA), VGA, QVGA, CIF, QCIF
|
|
Frame Rate
|
MPEG4 30fps@VGA
MJPEG 15fps@1280x960
|
|
Image Setting
|
Auto Exposure, Auto White Balance, Brightness, Contrast, Sharpness, Gamma, Mono, Reverse, Rotate 180, Flicker-less 50/60 Hz
|
|
Audio Codec
|
G.726
|
|
Digital Input
|
Dry Contact
|
|
Digital Output
|
Photo relay output: 40mA, 5~12VDC
|
|
Network
|
|
Interface
|
10/100 Ethernet (RJ-45)
|
|
Protocol
|
HTTP, TCP, UDP, SMTP, FTP, DHCP, NTP, UPnP, DynDNS, 3GPP/ISMA RTSP
|
|
Power over Ethernet
|
|
PoE Standard
|
IEEE 802.3af Power over Ethernet / PSE
|
|
PoE Power Supply Type
|
End-Span
|
|
PoE Power Output
|
Per Port 48V DC, 350mA. Max. 15.4 watts
|
|
Mechanical
|
|
Connectors
|
Power
|
DC Jack
|
|
Ethernet
|
RJ-45
|
|
Audio
|
1 In, 1 Out stereo phone jack, pitch 3.5 mm / 0.14 in
|
|
Digital I/O
|
4 pins terminal block, pitch 3.5 mm / 0.14 in
|
|
Auto Iris
|
Video drive & DC drive
|
|
LED Indicator
|
Power, Link, ACT
|
|
General
|
|
Operating Temperature
|
0C ~ 50C / 32 F ~ 122 F
|
| Humidity |
10% to 90% (no condensation) |
|
Power Source
|
DC12V / PoE
|
|
Power Comsumption
|
4.2 W (max. 350mA DC 12V)
|
|
Certificate
|
CE, FCC, RoHS compliant
|
|
Dimension
(L x W x H)
|
165 x 73 x 53 mm / 6.5 x 2.87 x 2.09 in
|
|
Weight
|
310g / 0.68 lb
|
|
Web Interface
|
|
Installation Management
|
Web-based configuration
|
|
Maintenance
|
Firmware upgrade through Web Browser
|
|
Access from Web Browser
|
Camera live view, video recording, change video quality, zoom in/out, bandwidth control, image snapshot, digital I/O control, audio, Picture in Picture, Picture and Picture, Privacy Mask, Visual Automation
|
|
Applications
|
|
Network Storage
|
GV-NVR, GV-System
|
|
3G Mobile Phone
|
Built-in player for 3GPP/ISMA
|
|
Live Viewing
|
MultiView, E-map, Mobile Phone
|
|
CMS Server support
|
Control Center, Center V2, VSM
|
