Video System:
|
NTSC / PAL (switchable) |
|
Video Compression Format:
|
Frame: MJPEG ; CIF: MPEG4 |
|
Video Input:
|
4 Channels. Composite video signal 1 Vp-p 75 BNC |
|
Video Loop Out:
|
4 Channels. Composite video signal 1 Vp-p 75 BNC |
|
Video Output:
|
Main Monitor Output: Composite video signal 1 Vp-p 75 BNC |
|
Call Monitor Output:
|
Composite video signal 1 Vp-p 75 BNC |
|
Maximum Recording Rate:
|
Frame: 720480 pixels with 30 IPS
/ 720576 pixels with 25 IPS
CIF: 352240 pixels with 120 IPS
/ 352288 pixels with 100 IPS
|
|
Adjustable Recording Speed Frame:
|
30, 15, 7, 3 IPS
/ 25, 12, 6, 3 IPS
CIF: 120, 60, 30, 15 IPS
/ 100, 50, 25, 12 IPS
|
|
Image Quality Setting:
|
Best, High, Normal and Basic |
|
Hard Disk Storage:
|
IDE type, ATA66, supported HDD, support HDD capacity over 400GB |
|
HDD Quick Cleaning:
|
Quick clean up the index system of the recorded files.
250GB under 2 seconds |
|
Recording Mode:
|
Manual / Timer / Motion / Alarm / Remote |
|
Refresh Rate:
|
120 IPS for NTSC / 100 IPS for PAL |
|
Audio I/O:
|
1 audio input, 1 audio output (Mono) |
|
Motion Detection Area:
|
16 12 grids per camera for all channels |
|
Motion Detect Sensitivity:
|
4 adjustable variables with precise calculation for
motion detection |
|
Pre-alarm Recording:
|
Yes (8MB) |
|
Backup Device:
|
Network remote backup |
|
Web Transmitting Compression Format:
|
Motion JPEG Ethernet 10/100 Base-T. Support
remote control and live view via Ethernet |
|
Web Interface:
|
Support licensed software AP and IE browser |
|
Remote Alarm Notification:
|
E-mail images, and upload images to FTP
sites specific account |
|
Network Connection:
|
Support TCP/IP, PPPoE, DHCP and DDNS function |
|
PTZ control:
|
Support PELCO-D protocol |
|
Dwell Time(Sequential Channel Switch):
|
Programmable with adjustable dwell time |
|
Alarm I/O:
|
4 inputs, 1 output |
|
Digital Zoom:
|
2x digital zoom (live mode) |
|
Key Lock:
|
Yes |
|
Video Loss Detection:
|
Yes |
|
Camera Title:
|
Support up to 6 letters |
|
Video Adjustable:
|
Hue / Color / Contrast / Brightness |
|
Date Display Format:
|
YY/MM/DD, DD/MM/YY, MM/DD/YY, and Off |
|
Power Source:
|
DC 19V |
|
Power Consumption
|
42 W |
|
Operating Temperature:
|
10C~ 40C (50F ~104F) |
|
Dimensions (mm):
|
343mm (W) 59mm (H) 223mm (D) |
|
System Recovery:
|
System auto recovery after power reconnected |
