| DVR Specifications |
|
Video System
|
NTSC / PAL (switchable) |
|
Video Compression Format
|
Frame: MJPEG ; CIF: MPEG4 |
|
Video Input
|
4 Channels. Composite video signal 1 Vp-p 75 BNC |
|
Video Loop Out
|
4 Channels. Composite video signal 1 Vp-p 75 BNC |
|
Video Output
|
Main Monitor Output: Composite video signal 1 Vp-p 75 BNC |
|
Call Monitor Output
|
Composite video signal 1 Vp-p 75 BNC |
|
Maximum Recording Rate Frame
|
NTSC: 720480 pixels with 30 IPS
PAL: 720576 pixels with 25 IPS
NTSC: CIF;352240 pixels with 120 IPS
PAL: 352288 pixels with 100 IPS |
|
Adjustable Recording Speed Frame
|
NTSC: 30, 15, 7, 3 IPS
PAL: 25, 12, 6, 3 IPS
NTSC: CIF;120, 60, 30, 15 IPS
PAL: 100, 50, 25, 12 IPS |
|
Image Quality Setting
|
Best, High, Normal and Basi |
|
Hard Disk Storage
|
IDE type, ATA66, supported HDD*1, support HDD capacity over 400GB |
|
HDD Quick Cleaning
|
Quick clean up the index system of the recorded files. 250GB under 2 seconds |
|
Recording Mode
|
Manual / Timer / Motion / Alarm / Remote |
|
Refresh Rate
|
120 IPS for NTSC / 100 IPS for PAL |
|
Audio I/O
|
1 audio input, 1 audio output (Mono) |
|
Motion Detection Area
|
16 12 grids per camera for all channels |
|
Motion Detect Sensitivity
|
4 adjustable variables with precise calculation |
|
Pre-alarm Recording
|
Yes (8Mb) |
|
Backup Device
|
Network remote backup |
|
Web Transmitting / Compression Format
|
Motion JPEG |
|
Ethernet
|
10/100 Base-T. Support remote control and live view via Ethernet |
|
Web Interface
|
Support licensed software AP and IE browser |
|
Remote Alarm Notification
|
E-mail images, and upload images to FTP sites specific account |
|
Network Connection
|
Support TCP/IP, PPPoE, DHCP and DDNS function |
|
PTZ control
|
Support PELCO-D protocol |
|
Sequential Channel Switch
|
Programmable with adjustable dwell time |
|
Alarm I/O
|
4 inputs, 1 output |
|
Digital Zoom
|
2 x digital zoom (live mode) |
|
Key Lock
|
Yes |
|
Video Loss Detection
|
Yes |
|
Camera Title
|
Support up to 6 letters |
|
Video Adjustable
|
Hue / Color / Contrast / Brightness |
|
Date Display Format
|
YY/MM/DD, DD/MM/YY, MM/DD/YY, and Off |
|
Power Source
|
DC 19V |
|
Power Consumption
|
42 W |
|
Operating Temperature
|
+10C ~ +40C (+50F ~ +104F) |
|
Dimensions (mm)
|
343mm (W) 59mm (H) 223mm (D) |
|
System Recovery
|
System auto recovery after power reconnected |
|
Optional Peripheral
|
VGA converter |
| Camera Specifications |
|
Image Resolution
|
|
|
Image Sensor
|
1/3 Super CMOS |
|
Video Quality
|
380 TV Lines |
|
No. of Effective Pixels
|
NTSC: 510(h) x 492(v)
PAL: 628(h) x 582(v) |
|
Minimum Illumination
|
0 Lux (IR on) |
|
Day/Night Mode
|
Automatic |
|
White Balance
|
Automatic |
|
Signal Ratio
|
> 48 dB |
|
Electronic Shutter
|
1/60~1/15,000 |
|
Auto Gain Control
|
Automatic |
|
Back Light Compensation
|
Automatic |
|
Lens
|
6mm standard |
|
Viewing Angle
|
54 degrees |
|
Night Vision
|
|
|
Number of Infra-Red
|
LEDs 30 |
|
Infra-Red Wavelength
|
850nm |
|
Night Vision Distance
|
30ft / 9m |
|
Infra-Red LED Life
|
100,000hrs |
|
General
|
|
|
Power Supply
|
DC 12V |
|
Operation Temperature
|
-10C ~ +50C (14F ~ 122F) |
|
Body
|
Plastic with metallic finish |
|
Dimensions
|
Camera 2.6 (l) x 2.6 (w) x 5.3 (h) / 65mm (l) x 65mm (w) x 135mm (h)
Camera with bracket 6.7 (l) x 2.6 (w) x 5.3 (h) / 170mm (l) x 65mm (w) x 135mm (h) |
|
Weight
|
Camera only 0.44lbs / 200g
Camera with bracket 0.55lbs / 250g |
|
Cable Length
|
60ft / 18m BNC |
